Larry Williams Donchian Breakout StrategyThis strategy is based on a breakout of the Donchian Channel with customizable risk-reward parameters and optional entry filters. It combines visual elements from the Donchian Channel indicator with a fully executable trading logic.
How entries are generated
A long trade is opened when the chosen signal price (either bar’s High or Close) closes above the upper Donchian Channel on each of the three previous bars.
A short trade is opened when the chosen signal price (either bar’s Low or Close) closes below the lower Donchian Channel on each of the three previous bars.
Both long and short signals can be configured to use either High/Low or Close values for confirmation.
Stop Loss and Take Profit
The Stop Loss is automatically placed relative to the Donchian middle line with a user-defined offset.
The Take Profit is calculated using a Risk/Reward multiplier.
Separate risk-reward ratios can be set for long and short positions.
Visual elements
The Donchian Channel (upper, lower, and middle bands) is plotted on the chart.
High-High, Higher-Low, Lower-High, and Lower-Low markers are displayed when pivot conditions are met.
Each trade is visualized with three horizontal lines drawn for a limited number of recent trades:
Entry (blue)
Stop Loss (red)
Take Profit (green)
To keep the chart clean, only the last ten trades (30 lines in total) remain visible.
Entry filters
Two optional filters are included and can be enabled or disabled independently:
LWTI filter – Long trades are only allowed when the Larry Williams Trade Index is green, and short trades are only allowed when the index is red.
Volume filter – Trades are only allowed when the current volume is above its 30-period SMA.
Use case
The strategy is designed to test Donchian Channel breakout conditions with risk management and simple filters. It can serve as a foundation for further development, allowing traders to experiment with additional filters or money management rules.
Disclaimer
This strategy is for educational and research purposes only. It is not financial advice. Always test thoroughly before using any strategy in live trading, and make trading decisions at your own risk.
Volumen
Whale Flow Trend DetectorWhat This Solves
Traditional volume indicators treat all volume equally. A retail trader buying $100 gets the same weight as an institution moving $10M. This indicator separates whale activity from retail noise to show you when the big players are actually establishing trend positions.
How It Works
Whale Detection Engine:
Identifies volume spikes 1.5x+ average with meaningful price impact
Multi-factor conviction scoring based on volume, price movement, and follow-through
Filters out retail noise and exchange glitches
Trend Flow Analysis:
Tracks cumulative whale direction over time (bullish vs bearish flow)
Shows trend regime changes when whale sentiment shifts
Flow strength meter (-100 to +100) for trend conviction
Conviction Levels:
EXTREME (🐋): Massive volume + big moves + trend alignment + confirmation
HIGH: Strong volume + decent impact + some follow-through
MEDIUM: Above-average activity with minor price impact
Why Crypto-Specific
Crypto markets offer unique advantages for whale detection:
Transparent volume data across all exchanges
24/7 trading shows true institutional vs retail patterns
Whale activity is more visible than traditional markets
No dark pools hiding large orders
Key Features
✅ Real-time whale activity detection
✅ Cumulative flow tracking for trend direction
✅ Multi-timeframe regime analysis
✅ Conviction-based signal filtering
✅ 6 comprehensive alert types
✅ Live whale activity dashboard
✅ Background regime coloring
What You See
Green triangles: Bullish whale activity
Red triangles: Bearish whale activity
Flow line: Cumulative whale sentiment (rising = bullish, falling = bearish)
Conviction labels: Details on volume ratio and price impact
Background colors: Current market regime (bullish/bearish/sideways)
Best Usage
Works on all timeframes but optimal on 4H+ where whale patterns develop.
Perfect for:
Trend following strategies
Institutional flow analysis
Regime change detection
Entry timing with whale confirmation
The Edge
While others chase every volume spike, this indicator shows you when volume actually matters. When whales move, trends follow. When whale flow shifts, regimes change.
Settings Guidance
Conservative: 2.0x volume multiplier, 0.2% min impact
Balanced: 1.5x volume multiplier, 0.1% min impact (default)
Aggressive: 1.2x volume multiplier, 0.05% min impact
BOCS Adaptive🚀 BOCS Adaptive - Advanced Dynamic Volatility Breakout Channel System
Enhanced version of AlgoAlpha's Smart Money Breakout Channels with adaptive ATR-based risk management for professional-grade trading signals.
📜 CREDITS & ATTRIBUTION:
This indicator is based on the original "Smart Money Breakout Channels" by AlgoAlpha (). Full credit goes to AlgoAlpha for the innovative breakout channel detection methodology. This enhanced version adds adaptive ATR-based TP/SL functionality and advanced volume analysis features.
🔬 THE BOCS METHODOLOGY EXPLAINED:
What is BOCS?
BOCS (Breakout Channel System) is AlgoAlpha's sophisticated algorithm that identifies high-probability breakout opportunities by analyzing normalized price volatility patterns. Unlike traditional support/resistance methods, BOCS uses mathematical normalization to detect when markets are consolidating before explosive moves.
📊 HOW THE CHANNEL DETECTION WORKS (Original AlgoAlpha Method):
Step 1: Price Normalization
Calculates the highest high and lowest low over a specified period (default 100 bars)
Normalizes current price position within this range: (close - lowest) / (highest - lowest)
This creates a 0-1 scale that works across all markets and timeframes
Step 2: Volatility Analysis
Applies standard deviation to the normalized price over 14 periods
Identifies volatility peaks and troughs using specialized algorithms
Tracks volatility cycles to predict consolidation phases
Step 3: Channel Formation
Detects when volatility crosses from high to low (consolidation begins)
Creates dynamic channels using the highest/lowest points during consolidation
Channels automatically expand/contract based on price action
Minimum 10-bar duration ensures meaningful consolidation patterns
Step 4: Breakout Detection
Strong Closes Mode: Requires >50% of candle body outside channel (reduces false signals from wicks)
Any Touch Mode: Triggers on any price movement outside channel boundaries
Volume confirmation analysis validates breakout strength
🆕 ENHANCED FEATURES (This Version):
⚡ Adaptive ATR Risk Management:
Revolutionary Volatility-Based TP/SL System:
Traditional fixed pip/tick stops don't account for changing market conditions. This enhanced version adds ATR (Average True Range) multipliers to create dynamic TP/SL levels that automatically adjust to current volatility.
ATR Calculation Process:
Select any timeframe for ATR source (1min, 5min, 15min, etc.)
Uses customizable period length (default 14) for smoothing
Calculates: TP Distance = ATR × Multiplier
Updates continuously as market volatility changes
Example Setup:
Chart: 5-minute NQ futures
ATR Source: 1-minute timeframe
Current 1min ATR: 4.36 points
TP1 Multiplier: 2.0 → TP1 = 8.72 points from entry
TP2 Multiplier: 3.5 → TP2 = 15.26 points from entry
SL Multiplier: 1.0 → SL = 4.36 points from entry
📈 ENHANCED VOLUME ANALYSIS SYSTEM:
Three Advanced Volume Modes (Enhanced from Original):
1. Volume Mode:
Displays total volume relative to 20-period moving average
Visual transparency indicates volume strength
Helps identify accumulation/distribution phases
2. Comparison Mode:
Separates up volume (green) vs down volume (red)
Shows buying vs selling pressure within channels
Critical for breakout direction bias
3. Delta Mode:
Calculates net volume delta (up volume - down volume)
Positive delta = buying pressure (above midline)
Negative delta = selling pressure (below midline)
Uses multi-timeframe data for granular analysis
🎯 VOLUME CONFIRMATION ALGORITHM (Enhanced):
Breakout Validation System:
Compares breakout volume to 20-period average
CONFIRMED: Volume >120% of average (strong breakout)
WEAK: Volume 80-120% of average (proceed with caution)
FAILED: Volume <80% of average (likely false breakout)
Volume Gauge Feature (New):
Real-time volume delta visualization
Color-coded pressure indicator (red to green spectrum)
Shows current positioning within high/low volume range
Updates continuously during active channels
📊 COMPREHENSIVE TRADE MONITORING (Enhanced):
Real-Time Analysis Table:
Trade status and direction
Channel formation status
Current ATR value and timeframe
Calculated TP/SL distances with multipliers
Last breakout analysis with volume confirmation
Current vs average volume comparison
Volume strength rating (Very High/High/Normal/Low)
🔔 INTELLIGENT ALERT SYSTEM (Enhanced):
Six Alert Types:
New Channel Formation - Consolidation pattern detected
Bullish Breakout - Upward channel break with entry price
Bearish Breakout - Downward channel break with entry price
Take Profit 1 Hit - First target reached (New)
Take Profit 2 Hit - Second target reached (New)
Stop Loss Hit - Risk management triggered (New)
🎨 VISUAL FEATURES (Enhanced):
Channel Visualization (Original AlgoAlpha Design):
Semi-transparent main channel box
Colored upper/lower zones (red=resistance, green=support)
Dashed center line for reference
Volume bars within channels
Real-time volume gauge (new)
TP/SL Display (New Enhancement):
White entry line with price label
Green TP lines with distance calculations
Red SL line with distance calculation
Customizable line lengths and colors
Shows both price levels AND point distances
⚙️ ADVANCED CUSTOMIZATION (Enhanced):
Original AlgoAlpha Settings:
Nested channels (multiple overlapping) or single channel mode
Strong closes only vs any touch breakouts
Normalization and detection lengths
Volume analysis timeframe selection
New ATR Risk Management Settings:
Independent ATR timeframe selection
Customizable ATR calculation period
Separate multipliers for TP1, TP2, and SL
Toggle TP2 on/off as needed
Enhanced Display Options:
Four table positions with offset controls
Three table sizes (Small/Normal/Large)
Volume text sizing and positioning
Complete color customization
Show/hide individual components
📈 OPTIMAL USE CASES:
Scalping (1-5 minute charts):
Use 1-minute ATR for responsive risk management
Enable strong closes mode for cleaner signals
Monitor volume confirmation closely
Day Trading (5-30 minute charts):
Use 5-minute ATR for balanced approach
Enable nested channels for multiple setups
Focus on volume delta for direction bias
Swing Trading (1-4 hour charts):
Use 15-30 minute ATR for stable levels
Longer detection periods for significant channels
Emphasize volume confirmation for major moves
📊 COMPATIBLE MARKETS:
✅ Forex pairs (EUR/USD, GBP/USD, USD/JPY, etc.)
✅ Stock indices (SPY, QQQ, IWM, DIA)
✅ Futures (ES, NQ, YM, RTY, CL, GC)
✅ Individual stocks (AAPL, TSLA, GOOGL, etc.)
✅ Cryptocurrencies (BTC, ETH, altcoins)
✅ Commodities (Gold, Silver, Oil, etc.)
🙏 ACKNOWLEDGMENTS:
Special thanks to AlgoAlpha for creating the original Smart Money Breakout Channels indicator and sharing it with the TradingView community. Their innovative approach to breakout detection formed the foundation for this enhanced version. Please support the original creator by checking out their other excellent indicators.
⚠️ RISK DISCLAIMER:
This indicator is designed for educational and analytical purposes only. Trading involves substantial risk of loss and is not suitable for all investors. Past performance does not guarantee future results. The BOCS Adaptive system, while sophisticated, should be used as part of a comprehensive trading strategy that includes proper risk management, position sizing, and market analysis. Always conduct your own due diligence and consider consulting with a qualified financial advisor before making trading decisions. No system can guarantee profitable trades, and users should never risk more than they can afford to lose.
tancanxThis indicator works on a single panel, featuring the Gaussian Filter to show price direction, Chandelier Exit-based stop levels, and volume-based strong signals.
Institutional Levels (CNN) - [PhenLabs]📊Institutional Levels (Convolutional Neural Network-inspired)
Version : PineScript™v6
📌Description
The CNN-IL Institutional Levels indicator represents a breakthrough in automated zone detection technology, combining convolutional neural network principles with advanced statistical modeling. This sophisticated tool identifies high-probability institutional trading zones by analyzing pivot patterns, volume dynamics, and price behavior using machine learning algorithms.
The indicator employs a proprietary 9-factor logistic regression model that calculates real-time reaction probabilities for each detected zone. By incorporating CNN-inspired filtering techniques and dynamic zone management, it provides traders with unprecedented accuracy in identifying where institutional money is likely to react to price action.
🚀Points of Innovation
● CNN-Inspired Pivot Analysis - Advanced binning system using convolutional neural network principles for superior pattern recognition
● Real-Time Probability Engine - Live reaction probability calculations using 9-factor logistic regression model
● Dynamic Zone Intelligence - Automatic zone merging using Intersection over Union (IoU) algorithms
● Volume-Weighted Scoring - Time-of-day volume Z-score analysis for enhanced zone strength assessment
● Adaptive Decay System - Intelligent zone lifecycle management based on touch frequency and recency
● Multi-Filter Architecture - Optional gradient, smoothing, and Difference of Gaussians (DoG) convolution filters
🔧Core Components
● Pivot Detection Engine - Advanced pivot identification with configurable left/right bars and ATR-normalized strength calculations
● Neural Network Binning - Price level clustering using CNN-inspired algorithms with ATR-based bin sizing
● Logistic Regression Model - 9-factor probability calculation including distance, width, volume, VWAP deviation, and trend analysis
● Zone Management System - Intelligent creation, merging, and decay algorithms for optimal zone lifecycle control
● Visualization Layer - Dynamic line drawing with opacity-based scoring and optional zone fills
🔥Key Features
● High-Probability Zone Detection - Automatically identifies institutional levels with reaction probabilities above configurable thresholds
● Real-Time Probability Scoring - Live calculation of zone reaction likelihood using advanced statistical modeling
● Session-Aware Analysis - Optional filtering to specific trading sessions for enhanced accuracy during active market hours
● Customizable Parameters - Full control over lookback periods, zone sensitivity, merge thresholds, and probability models
● Performance Optimized - Efficient processing with controlled update frequencies and pivot processing limits
● Non-Repainting Mode - Strict mode available for backtesting accuracy and live trading reliability
🎨Visualization
● Dynamic Zone Lines - Color-coded support and resistance levels with opacity reflecting zone strength and confidence scores
● Probability Labels - Real-time display of reaction probabilities, touch counts, and historical hit rates for active zones
● Zone Fills - Optional semi-transparent zone highlighting for enhanced visual clarity and immediate pattern recognition
● Adaptive Styling - Automatic color and opacity adjustments based on zone scoring and statistical significance
📖Usage Guidelines
● Lookback Bars - Default 500, Range 100-1000, Controls the historical data window for pivot analysis and zone calculation
● Pivot Left/Right - Default 3, Range 1-10, Defines the pivot detection sensitivity and confirmation requirements
● Bin Size ATR units - Default 0.25, Range 0.1-2.0, Controls price level clustering granularity for zone creation
● Base Zone Half-Width ATR units - Default 0.25, Range 0.1-1.0, Sets the minimum zone width in ATR units for institutional level boundaries
● Zone Merge IoU Threshold - Default 0.5, Range 0.1-0.9, Intersection over Union threshold for automatic zone merging algorithms
● Max Active Zones - Default 5, Range 3-20, Maximum number of zones displayed simultaneously to prevent chart clutter
● Probability Threshold for Labels - Default 0.6, Range 0.3-0.9, Minimum reaction probability required for zone label display and alerts
● Distance Weight w1 - Controls influence of price distance from zone center on reaction probability
● Width Weight w2 - Adjusts impact of zone width on probability calculations
● Volume Weight w3 - Modifies volume Z-score influence on zone strength assessment
● VWAP Weight w4 - Controls VWAP deviation impact on institutional level significance
● Touch Count Weight w5 - Adjusts influence of historical zone interactions on probability scoring
● Hit Rate Weight w6 - Controls prior success rate impact on future reaction likelihood predictions
● Wick Penetration Weight w7 - Modifies wick penetration analysis influence on probability calculations
● Trend Weight w8 - Adjusts trend context impact using ADX analysis for directional bias assessment
✅Best Use Cases
● Swing Trading Entries - Enter positions at high-probability institutional zones with 60%+ reaction scores
● Scalping Opportunities - Quick entries and exits around frequently tested institutional levels
● Risk Management - Use zones as dynamic stop-loss and take-profit levels based on institutional behavior
● Market Structure Analysis - Identify key institutional levels that define current market structure and sentiment
● Confluence Trading - Combine with other technical indicators for high-probability trade setups
● Session-Based Strategies - Focus analysis during high-volume sessions for maximum effectiveness
⚠️Limitations
● Historical Pattern Dependency - Algorithm effectiveness relies on historical patterns that may not repeat in changing market conditions
● Computational Intensity - Complex calculations may impact chart performance on lower-end devices or with multiple indicators
● Probability Estimates - Reaction probabilities are statistical estimates and do not guarantee actual market outcomes
● Session Sensitivity - Performance may vary significantly between different market sessions and volatility regimes
● Parameter Sensitivity - Results can be highly dependent on input parameters requiring optimization for different instruments
💡What Makes This Unique
● CNN Architecture - First indicator to apply convolutional neural network principles to institutional-level detection
● Real-Time ML Scoring - Live machine learning probability calculations for each zone interaction
● Advanced Zone Management - Sophisticated algorithms for zone lifecycle management and automatic optimization
● Statistical Rigor - Comprehensive 9-factor logistic regression model with extensive backtesting validation
● Performance Optimization - Efficient processing algorithms designed for real-time trading applications
🔬How It Works
● Multi-timeframe pivot identification - Uses configurable sensitivity parameters for advanced pivot detection
● ATR-normalized strength calculations - Standardizes pivot significance across different volatility regimes
● Volume Z-score integration - Enhanced pivot weighting based on time-of-day volume patterns
● Price level clustering - Neural network binning algorithms with ATR-based sizing for zone creation
● Recency decay applications - Weights recent pivots more heavily than historical data for relevance
● Statistical filtering - Eliminates low-significance price levels and reduces market noise
● Dynamic zone generation - Creates zones from statistically significant pivot clusters with minimum support thresholds
● IoU-based merging algorithms - Combines overlapping zones while maintaining accuracy using Intersection over Union
● Adaptive decay systems - Automatic removal of outdated or low-performing zones for optimal performance
● 9-factor logistic regression - Incorporates distance, width, volume, VWAP, touch history, and trend analysis
● Real-time scoring updates - Zone interaction calculations with configurable threshold filtering
● Optional CNN filters - Gradient detection, smoothing, and Difference of Gaussians processing for enhanced accuracy
💡Note
This indicator represents advanced quantitative analysis and should be used by traders familiar with statistical modeling concepts. The probability scores are mathematical estimates based on historical patterns and should be combined with proper risk management and additional technical analysis for optimal trading decisions.
CNagda Anchor2EntryCNagda Anchor2Entry Pine Script v6 overlay indicator pulls higher-timeframe (HTF) signal events to define anchor high/low levels and then projects visual entry labels on the lower-timeframe (LTF). It also draws auto-oriented Fibonacci retracement/extension levels for context, but it does not execute orders, stops, or targets—only visual guidance.
Inputs
Key inputs include Lookback Length for HTF scanning and a Signal Timeframe used with request.security to import HTF events onto the active chart.
Entry behavior can be set to “Confirm only” or “Wait candle,” trade side can be restricted to Buy/Sell/Both, and individual strategies (Buy WAIT/S1; Sell REV/S1/S2/S3) can be toggled.
HTF logic
The script defines WAIT/BUY setup and confirmation, SELL reversal on breaking the WAIT BUY low, and several volume/candle-based patterns (Sell S1/S2/S3, Buy S1).
It captures the associated highs/lows at those events with ta.valuewhen and imports them via request.security to form anchors (anc_hi/anc_lo) and “new trigger” booleans that gate label creation on the LTF.
Flip entries
When enabled, “Flip entries” generate contrarian labels based on breaking or confirming HTF anchors: crossing above anc_hi can trigger a flip-to-sell label, and crossing below anc_lo can trigger a flip-to-buy label.
The flip mode supports Immediate (on cross) or Confirm (on sustained break) to control how strict the trigger is.
Fibonacci drawing
User-specified Fib levels are parsed from a string, safely converted to floats, and drawn as dotted horizontal lines only when they fall inside an approximate visible viewport. Orientation (up or down) is decided automatically from pending signal direction and a simple context score (candle bias, trend, and price vs. mid), with efficient redraw/clear guards to avoid clutter.
Dynamic anchors
If HTF anchors are missing or too far from current price (checked with an ATR-based threshold), the script falls back to local swing highs/lows to keep the reference range relevant. This dynamic switch helps Fib levels and labels remain close to current market structure without manual intervention.
Signal labels
Labels are created only on confirmed bars to avoid repainting noise, with one “latest” label kept by deleting the previous one. The script places BUY/SELL labels for WAIT/CONFIRM, direct HTF patterns (Buy S1, Sell S1/S2/S3), and contrarian flip events, offset slightly from highs/lows with clear coloring and configurable sizes.
Visual context
Bars are softly colored (lime tint for bullish, orange tint for bearish) for quick context, and everything renders as an overlay on the price chart. Fib labels include a Δ readout (distance from current close), and line extension length, label sizes, and viewport padding are adjustable.
How to use
Set the Signal Timeframe and Lookback Length to establish which HTF structures and ranges will drive the anchors and entry conditions. Choose entry flow (Wait vs Confirm), enable Flip if contrarian triggers are desired, select the trade side, toggle strategies, and customize Fibonacci levels plus dynamic-anchor fallback for practical on-chart guidance.
Notes
This is a visual decision-support tool; it does not place trades, stops, or targets and should be validated on charts before live use. It is written for Pine Script v6 and relies heavily on request.security for HTF-to-LTF transfer of signals and anchors.
TSLA Scalping Signals (Volume + RSI + MACD + VWAP)//@version=5
indicator("TSLA Scalping Signals (Volume + RSI + MACD + VWAP)", overlay=true, timeframe="", timeframe_gaps=true)
// =========================
// 사용자 입력(파라미터)
// =========================
// RSI 길이와 과매도/과매수 기준
rsiLen = input.int(5, "RSI 길이", minval=2)
rsiLow = input.int(35, "RSI 과매도 기준", minval=5, maxval=50)
rsiHigh = input.int(70, "RSI 과매수 기준", minval=50, maxval=95)
// MACD 파라미터
fastLen = input.int(12, "MACD Fast", minval=1)
slowLen = input.int(26, "MACD Slow", minval=2)
sigLen = input.int(9, "MACD Signal", minval=1)
// 거래량 스파이크 판단용
volSmaLen = input.int(20, "거래량 SMA 길이", minval=5)
volSpikeMult = input.float(1.5, "거래량 스파이크 배수", minval=0.5, step=0.1)
// 손절/익절(선택)
useStops = input.bool(true, "손절/익절 사용")
stopATRlen = input.int(14, "ATR 길이", minval=5)
stopATRmult = input.float(1.2, "손절 ATR 배수", minval=0.5, step=0.1)
tpRR = input.float(1.5, "익절 R 비율(손절의 배수)", minval=0.5, step=0.1)
// =========================
// 지표 계산부
// =========================
// VWAP: 단타 기준 핵심 추세선
vwap = ta.vwap(close)
// RSI(단기)
rsi = ta.rsi(close, rsiLen)
// MACD
macd = ta.ema(close, fastLen) - ta.ema(close, slowLen)
sig = ta.ema(macd, sigLen)
hist = macd - sig
// 거래량 스파이크: 현재 거래량이 거래량 SMA * 배수 이상인지
volSma = ta.sma(volume, volSmaLen)
volSpike = volume > volSma * volSpikeMult
// =========================
// 진입/청산 조건
// =========================
// 롱 진입 조건:
// 1) 가격 VWAP 위
// 2) MACD 상향 교차
// 3) RSI가 rsiLow 아래→위로 돌파
// 4) 거래량 스파이크
longCond = close > vwap and ta.crossover(macd, sig) and ta.crossover(rsi, rsiLow) and volSpike
// 롱 청산 조건(부분 청산/전체 청산 판단은 사용자 재량):
// A) RSI 과매수 도달, 또는
// B) MACD 하향 교차, 또는
// C) 가격이 VWAP 아래로 종가 이탈하면서 거래량 약화(현재 거래량 < volSma)
exitCond = (rsi > rsiHigh) or ta.crossunder(macd, sig) or (close < vwap and volume < volSma)
// =========================
// 시각적 표시
// =========================
plot(vwap, "VWAP", linewidth=2)
plotshape(longCond, title="BUY", style=shape.labelup, text="BUY", location=location.belowbar, size=size.tiny)
plotshape(exitCond, title="SELL", style=shape.labeldown, text="SELL", location=location.abovebar, size=size.tiny)
// 보조 하단창: RSI, MACD는 별도 패널이 일반적이므로 값만 툴팁용 표시
// (원하면 아래 plot들을 꺼도 됨)
rsiPlot = plot(rsi, title="RSI(단기)", color=color.new(color.blue, 0), display=display.none)
h1 = hline(rsiLow, "RSI 과매도", color=color.new(color.teal, 50))
h2 = hline(rsiHigh, "RSI 과매수", color=color.new(color.red, 50))
// =========================
// 간단 손절/익절 레벨(선택)
// =========================
// 매수 발생 바의 가격을 기준으로 ATR 손절/익절 레벨 산출
atr = ta.atr(stopATRlen)
var float entryPrice = na
var float stopPrice = na
var float takePrice = na
// 롱 진입 시 가격 고정
if (longCond)
entryPrice := close
stopPrice := useStops ? (close - atr * stopATRmult) : na
takePrice := useStops ? (close + (close - stopPrice) * tpRR) : na
// 청산 신호 시 초기화
if (exitCond)
entryPrice := na
stopPrice := na
takePrice := na
plot(entryPrice, "Entry", color=color.new(color.green, 60), style=plot.style_circles, linewidth=2)
plot(stopPrice, "Stop", color=color.new(color.red, 60), style=plot.style_linebr, linewidth=2)
plot(takePrice, "Take", color=color.new(color.blue, 60), style=plot.style_linebr, linewidth=2)
// =========================
// 알림 조건
// =========================
alertcondition(longCond, title="BUY Signal", message="BUY signal: VWAP↑, MACD cross↑, RSI cross↑, Volume spike.")
alertcondition(exitCond, title="SELL Signal", message="SELL signal: RSI high or MACD cross↓ or below VWAP with weak volume.")
VWAP Bollinger CrossBased on the crossover of the moving average and VWAP, this indicator can help you find a trend. It is not recommended to use it only for entries. Try it and I hope it can help you.
Foresight Cone (HoltxF1xVWAP) [KedArc Quant]Description:
This is a time-series forecasting indicator that estimates the next bar (F1) and projects a path a few bars ahead. It also draws a confidence cone based on how accurate the recent forecasts have been. You can optionally color the projection only when price agrees with VWAP.
Why it’s different
* One clear model: Everything comes from Holt’s trend-aware forecasting method—no mix of unrelated indicators.
* Transparent visuals: You see the next-bar estimate (F1), the forward projection, and a cone that widens or narrows based on recent forecast error.
* Context, not signals: The VWAP option only changes colors. It doesn’t add trade rules.
* No look-ahead: Accuracy is measured using the forecast made on the previous bar versus the current bar.
Inputs (what they mean)
* Source: Price series to forecast (default: Close).
* Preset: Quick profiles for fast, smooth, or momentum markets (see below).
* Alpha (Level): How fast the model reacts to new prices. Higher = faster, twitchier.
* Beta (Trend): How fast the model updates the slope. Higher = faster pivots, more flips in chop.
* Horizon: How many bars ahead to project. Bigger = wider cone.
* Residual Window: How many bars to judge recent accuracy. Bigger = steadier cone.
* Confidence Z: How wide the cone should be (typical setting ≈ “95% style” width).
* Show Bands / Draw Forward Path: Turn the cone and forward lines on/off.
* Color only when aligned with VWAP: Highlights projections only when price agrees with the trend side of VWAP.
* Colors / Show Panel: Styling plus a small panel with RMSE, MAPE, and trend slope.
Presets (when to pick which)
* Scalp / Fast (1-min): Very responsive; best for quick moves. More twitch in chop.
* Smooth Intraday (1–5 min): Calmer and steadier; a good default most days.
* Momentum / Breakout: Quicker slope tracking during strong pushes; may over-react in ranges.
* Custom: Set your own values if you know exactly what you want.
What is F1 here?
F1 is the model’s next-bar fair value. Crosses of price versus F1 can hint at short-term momentum shifts or mean-reversion, especially when viewed with VWAP or the cone.
How this helps
* Gives a baseline path of where price may drift and a cone that shows normal wiggle room.
* Helps you tell routine noise (inside cone) from information (edges or breaks outside the cone).
* Keeps you aware of short-term bias via the trend slope and F1.
How to use (step by step)
1. Add to chart → choose a Preset (start with Smooth Intraday).
2. Set Horizon around 8–15 bars for intraday.
3. (Optional) Turn on VWAP alignment to color only when price agrees with the trend side of VWAP.
4. Watch where price sits relative to the cone and F1:
* Inside = normal noise.
* At edges = stretched.
* Outside = possible regime change.
5. Check the panel: if RMSE/MAPE spike, expect a wider cone; consider a smoother preset or a higher timeframe.
6. Tweak Alpha/Beta only if needed: faster for momentum, slower for chop.
7. Combine with your own plan for entries, exits, and risk.
Accuracy Panel — what it tells you
Preset & Horizon: Shows which preset you’re using and how many bars ahead the projection goes. Longer horizons mean more uncertainty.
RMSE (error in price units): A “typical miss” measured in the chart’s currency (e.g., ₹).
Lower = tighter fit and a usually narrower cone. Rising = conditions getting noisier; the cone will widen.
MAPE (error in %): The same idea as RMSE but in percent.
Good for comparing different symbols or timeframes. Sudden spikes often hint at a regime change.
Slope T: The model’s short-term trend reading.
Positive = gentle up-bias; negative = gentle down-bias; near zero = mostly flat/drifty.
How to read it at a glance
Calm & directional: RMSE/MAPE steady or falling + Slope T positive (or negative) → trends tend to respect the cone’s mid/upper (or mid/lower) area.
Choppy/uncertain: RMSE/MAPE climbing or jumping → expect more whipsaw; rely more on the cone edges and higher-TF context.
Flat tape: Slope T near zero → mean-revert behavior is common; treat cone edges as stretch zones rather than breakout zones.
Warm-up & tweaks
Warm-up: Right after adding the indicator, the panel may be blank for a short time while it gathers enough bars.
Too twitchy? Switch to Smooth Intraday or increase the Residual Window.
Too slow? Use Scalp/Fast or Momentum/Breakout to react quicker.
Timeframe tips
* 1–3 min: Scalp/Fast or Momentum/Breakout; horizon \~8–12.
* 5–15 min: Smooth Intraday; horizon \~12–15.
* 30–60 min+: Consider a larger residual window for a steadier cone.
FAQ
Q: Is this a strategy or an indicator?
A: It’s an indicator only. It does not place orders, TP/SL, or run backtests.
Q: Does it repaint?
A: The next-bar estimate (F1) and the cone are calculated using only information available at that time. The forward path is a projection drawn on the last bar and will naturally update as new bars arrive. Historical bars aren’t revised with future data.
Q: What is F1?
A: F1 is the indicator’s best guess for the next bar.
Price crossing above/below F1 can hint at short-term momentum shifts or mean-reversion.
Q: What do “Alpha” and “Beta” do?
A: Alpha controls how fast the indicator reacts to new prices
(higher = faster, twitchier). Beta controls how fast the slope updates (higher = quicker pivots, more flips in chop).
Q: Why does the cone width change?
A: It reflects recent forecast accuracy. When the market gets noisy, the cone widens. When the tape is calm, it narrows.
Q: What does the Accuracy Panel tell me?
A:
* Preset & Horizon you’re using.
* RMSE: typical forecast miss in price units.
* MAPE: typical forecast miss in percent.
* Slope T: short-term trend reading (up, down, or flat).
If RMSE/MAPE rise, expect a wider cone and more whipsaw.
Q: The panel shows “…” or looks empty. Why?
A: It needs a short warm-up to gather enough bars. This is normal after you add the indicator or change settings/timeframes.
Q: Which timeframe is best?
A:
* 1–3 min: Scalp/Fast or Momentum/Breakout, horizon \~8–12.
* 5–15 min: Smooth Intraday, horizon \~12–15.
Higher timeframes work too; consider a larger residual window for steadier cones.
Q: Which preset should I start with?
A: Start with Smooth Intraday. If the market is trending hard, try Momentum/Breakout.
For very quick tapes, use Scalp/Fast. Switch back if things get choppy.
Q: What does the VWAP option do?
A: It only changes colors (highlights when price agrees with the trend side of VWAP).
It does not add or remove signals.
Q: Are there alerts?
A: Yes—alerts for price crossing F1 (up/down). Use “Once per bar close” to reduce noise on fast charts.
Q: Can I use this on stocks, futures, crypto, or FX?
A: Yes. It works on any symbol/timeframe. You may want to adjust Horizon and the Residual Window based on volatility.
Q: Can I use it with Heikin Ashi or other non-standard bars?
A: You can, but remember you’re forecasting the synthetic series of those bars. For pure price behavior, use regular candles.
Q: The cone feels too wide/too narrow. What do I change?
A:
* Too wide: lower Alpha/Beta a bit or increase the Residual Window.
* Too narrow (misses moves): raise Alpha/Beta slightly or try Momentum/Breakout.
Q: Why do results change when I switch timeframe or symbol?
A: Different noise levels and trends. The accuracy stats reset per chart, so the cone adapts to each context.
Q: Any limits or gotchas?
A: Extremely large Horizon may hit TradingView’s line-object limits; reduce Horizon or turn
off extra visuals if needed. Big gaps or news spikes will widen errors—expect the cone to react.
Q: Can this predict exact future prices?
A: No. It provides a baseline path and context. Always combine with your own rules and risk management.
Glossary
* TS (Time Series): Data over time (prices).
* Holt’s Method: A forecasting approach that tracks a current level and a trend to predict the next bars.
* F1: The indicator’s best guess for the next bar.
* F(h): The projected value h bars ahead.
* VWAP: Volume-Weighted Average Price—used here for optional color alignment.
* RMSE: Typical forecast miss in price units (how far off, on average).
* MAPE: Typical forecast miss in percent (scale-free, easy to compare).
Notes & limitations
* The panel needs a short warm-up; stats may be blank at first.
* The cone reflects recent conditions; sudden volatility changes will widen it.
* This is a tool for context. It does not place trades and does not promise results.
⚠️ Disclaimer
This script is provided for educational purposes only.
Past performance does not guarantee future results.
Trading involves risk, and users should exercise caution and use proper risk management when applying this strategy.
All-In-One: RSI+MACD+ATR+ADX+OBV by Roshan MenonThis is an all in one indicator bundle for free users. It has RSI, MACD, ATR,ADX,OBV , Enjoy!!!
RSI + MACD Combined with Volume Alert (Compact)"All-in-one momentum, timing, and conviction — built for serious day traders."
RSI + MACD Combined with Volume Alert (Compact)
This custom indicator is designed for traders who need precision and clarity across multiple timeframes (4H, 1H, 15M).
🔹 RSI (Yellow Line):
Tracks momentum and overbought/oversold levels. The 50 midline is emphasized as a directional bias filter — above favors long setups, below favors short setups.
🔹 MACD (Orange & Blue Lines):
Normalized to align with RSI’s scale for easy comparison. Provides crossover timing for entries/exits without clutter.
🔹 MACD Histogram (Red/Green Bars):
Shows impulse strength and divergence confirmation.
🔹 Volume Alerts (Purple Highlights):
High-volume conditions are marked when current volume exceeds 1.5× the 20-period average. This helps confirm valid breakouts/retracements and avoid low-liquidity traps.
🔹 Background Highlights:
Red when RSI > Overbought (70) → possible reversal zone.
Green when RSI < Oversold (30) → possible bounce zone.
✅ Why this indicator?
Combines momentum (RSI), timing (MACD), and conviction (Volume) in one panel.
Compact and color-coded for fast decision-making in day trading.
Optimized for gold (XAUUSD) and high-volatility assets, but adaptable to all markets.
Recommended Use:
4H → Confirm higher-timeframe bias.
1H → Identify actionable setups.
15M → Fine-tune entries at zones.
Volume ClusteringThis Volume Clustering script is a powerful tool for analyzing intraday trading dynamics by combining two key metrics: volume Z-Score and Cumulative Volume Delta (CVD). By categorizing market activity into distinct clusters, it helps you identify high-conviction trading opportunities and understand underlying market pressure.
How It Works
The script operates on a simple, yet effective, premise: it classifies each trading bar based on its statistical significance (volume Z-Score) and buying/selling pressure (CVD).
Volume Z-Score
The volume Z-Score measures how far the current bar's volume is from its average, helping to identify periods of unusually high or low volume. This metric is a powerful way to spot when institutional or large players might be entering the market. A high Z-Score suggests a significant event is taking place, regardless of direction.
Cumulative Volume Delta (CVD)
CVD tracks the net buying and selling pressure across different timeframes. The script uses a lower timeframe (e.g., 1-minute) and anchors it to a higher timeframe (e.g., 1-day) to capture intraday pressure. A positive CVD indicates more buying pressure, while a negative CVD suggests more selling pressure.
Cluster Categories
The script analyzes the confluence of these two metrics to assign a cluster to each bar, providing actionable insights. The clusters are color-coded and labeled to make them easy to interpret:
🟢 High Conviction Bullish: Unusually high volume (high Z-Score) combined with significant buying pressure (high CVD). This cluster suggests strong bullish momentum.
🔴 High Conviction Bearish: Unusually high volume (high Z-Score) coupled with significant selling pressure (low CVD). This cluster suggests strong bearish momentum.
🟡 Low Conviction/Noise: Low to moderate volume and mixed buying/selling pressure. This represents periods of indecision or consolidation, where market noise is more prevalent.
🟣 Other Clusters: The script also identifies other combinations, such as high volume with moderate CVD, or low volume with high CVD, which can provide additional context for understanding market dynamics.
Key Features & Customization
The script offers several customizable settings to tailor the analysis to your specific trading style:
Z-Score Lookback Length: Adjust the lookback period for calculating the average volume. A shorter period focuses on recent volume trends, while a longer period provides a broader context.
CVD Anchor & Lower Timeframe: Define the timeframes used for CVD calculation. You can anchor the analysis to a daily or weekly timeframe while using a lower timeframe (e.g., 1-minute) to capture granular intraday pressure.
High/Low Volume Mode: Toggle between "High Volume" mode (which uses 90th and 10th percentiles for clustering) and "Low Volume" mode (which uses 75th and 25th percentiles). This allows you to choose whether to focus on extreme events or more subtle shifts in market sentiment.
NY Anchored VWAP and Auto SMAThis NY Anchored VWAP and Auto SMA script is a powerful combination of two of the most popular technical indicators, designed to help you identify the intraday trend and potential shifts in market momentum. It stands out by automatically adjusting to current volatility, providing more adaptive and reliable signals than standard moving averages.
How It Works
This script combines a New York session-anchored VWAP with a dynamic Simple Moving Average (SMA) that automatically adjusts its length based on market volatility.
New York Anchored VWAP: The VWAP (Volume-Weighted Average Price) resets at the beginning of the New York trading session. This allows it to accurately track the average price paid by traders for the day, providing a key benchmark for identifying whether the price is trading at a premium or a discount relative to the volume-driven trend. The color of the VWAP line itself changes to indicate its slope: green for an upward trend and red for a downward trend.
Auto SMA: The script calculates a Simple Moving Average (SMA) but with a twist. It uses the Average True Range (ATR) to measure market volatility. When volatility is high, the SMA's lookback period automatically shortens to make it more responsive to price changes. Conversely, when volatility is low, the lookback period lengthens to smooth out the data and reduce noise. This dynamic adjustment helps the SMA stay relevant in all market conditions.
Key Features
Adaptive Lookback: The Auto SMA dynamically adjusts to market volatility, providing more responsive signals during volatile periods and smoother, more reliable signals during calm periods.
Color-Coded VWAP: The VWAP line changes color to instantly show the direction of the trend, making it easy to see at a glance if the average price is rising or falling.
Automated Alerts: The script provides automated alerts for when the VWAP crosses above or below the Auto SMA, signaling potential bullish or bearish momentum shifts.
Customizable Settings: You can hide the VWAP on daily or higher timeframes and change the source for the VWAP calculation to suit your specific trading style.
This tool is perfect for intraday and swing traders who want a more intelligent and adaptive way to measure trend direction and identify potential trading opportunities.
Volume DMAO [DCAUT]█ Volume DMAO Indicator
📊 OVERVIEW
The Volume DMAO (Dual Moving Average Oscillator) applies PPO-style calculation to volume data rather than price. It measures the percentage difference between fast and slow moving averages of volume, providing insights into volume momentum and market participation trends.
🎯 CONCEPTS
Signal Interpretation
Positive Values : Current volume above historical average (expansion phase)
Negative Values : Current volume below historical average (contraction phase)
Rising Trend : Volume momentum accelerating (increasing participation)
Falling Trend : Volume momentum decelerating (decreasing participation)
Primary Applications
Volume Confirmation : Validate price movements with volume momentum analysis
Divergence Detection : Spot potential reversals when volume diverges from price
Trend Strength : Assess volume participation in price trends
Entry/Exit Signals : Time trades based on volume momentum shifts
📋 PARAMETER SETUP
Input Parameters
Fast Length : Period for fast moving average (default: 12)
Slow Length : Period for slow moving average (default: 50)
MA Type : Moving average algorithm (default: EMA)
📊 COLOR CODING
Histogram Colors
Dark Green : Positive and rising (strong volume expansion)
Light Green : Positive and falling (weakening volume expansion)
Light Red : Negative and rising (recovering from volume contraction)
Dark Red : Negative and falling (strong volume contraction)
💡 CORE VALUE
Unlike traditional volume indicators, Volume DMAO provides normalized percentage readings that:
- Enable comparison across different timeframes and instruments
- Reveal volume momentum changes before price movements
- Identify market phases through volume participation analysis
Volume-Weighted RSI & Multi-Normalized MACD### Description for Publishing: Volume-Weighted RSI & Multi-Normalized MACD
**Overview**
The "Volume-Weighted RSI & Multi-Normalized MACD" indicator is a powerful and versatile tool designed for traders seeking enhanced momentum and trend analysis. Combining a volume-weighted Relative Strength Index (VW-RSI) with a customizable Moving Average Convergence Divergence (MACD) featuring multiple normalization methods, this indicator provides deep insights into market dynamics. It supports multi-timeframe (MTF) analysis and includes an optional stepped plotting mode for discrete signal visualization, making it ideal for both trend-following and mean-reversion strategies across various markets (stocks, forex, crypto, etc.).
**Key Features**
1. **Volume-Weighted RSI (VW-RSI)**:
- A modified RSI that incorporates trading volume for greater sensitivity to market activity.
- Normalized to a user-defined range (default: -50 to +50) for consistent analysis.
- Optional smoothing with multiple moving average types (SMA, EMA, WMA, VWMA, SMMA, or SMA with Bollinger Bands) to reduce noise and highlight trends.
- Overbought (+20) and oversold (-20) levels for quick reference.
2. **Multi-Normalized MACD**:
- Offers six normalization methods for MACD, allowing traders to tailor the output to their strategy:
- Normalized Volume Weighted MACD (unbounded).
- Min-Max Normalization (bounded).
- Volatility Normalization (unbounded, volatility-adjusted).
- Volatility Normalization with Min-Max (bounded).
- Hyperbolic Tangent Normalization (bounded).
- Arctangent Normalization (bounded).
- Min-Max with Smoothing (bounded).
- All bounded methods scale to the user-defined range (default: -50 to +50), ensuring comparability with VW-RSI.
- Dynamic color changes for MACD line (lime/red) and histogram (aqua/blue/red/maroon) based on momentum and signal line crosses.
3. **Stepped Plotting Mode**:
- Optional mode to plot RSI and MACD as discrete, stepped lines, reducing noise by only updating when values change significantly (configurable thresholds).
- Ideal for traders focusing on clear, actionable signal changes.
4. **Multi-Timeframe Support**:
- Configurable timeframe input (default: chart timeframe) for analyzing RSI and MACD on higher or lower timeframes, enhancing cross-timeframe strategies.
5. **Customizable Display**:
- Toggle options to show/hide MACD line, signal line, histogram, and cross dots.
- Bollinger Bands for RSI smoothing (optional) with adjustable standard deviation multiplier.
- Clear visual cues with horizontal lines for overbought/oversold levels, midline, and MACD bounds.
**Usage Instructions**
1. **Add to Chart**: Apply the indicator to any symbol (e.g., BTCUSD, SPY) on any timeframe (1H, 1D, etc.).
2. **Configure Settings**:
- **General**: Adjust `Lower Bound` (-50 default) and `Upper Bound` (+50 default) for the output range. Set `Timeframe` for MTF analysis. Enable `Stepped?` for discrete plotting.
- **RSI**: Choose `Price Source` (default: ohlc4), `RSI Length` (default: 9), and smoothing options (e.g., EMA, Bollinger Bands). Adjust `RSI Diff Threshold` for stepped mode.
- **MACD**: Select `Price Source`, `Fast Length` (9), `Slow Length` (21), `Signal Length` (9), and a normalization method (default: Volatility Min-Max). Adjust `MACD Diff Threshold` for stepped mode.
- **Display Options**: Toggle MACD components and histogram colors for clarity.
3. **Interpretation**:
- **VW-RSI**: Watch for crosses above +20 (overbought) or below -20 (oversold) for potential reversals. Use smoothed RSI or Bollinger Bands for trend confirmation.
- **MACD**: Look for MACD/Signal line crosses (dots indicate crossings) and histogram changes for momentum shifts. Bounded normalizations align with RSI for unified analysis.
- **Stepped Mode**: Focus on significant changes in RSI/MACD for clearer signals.
4. **Companion Overlay**: For visualization on the main price chart, use the companion script "VW-RSI & MACD Price Overlay" (available separately, requires this script to be published). It plots RSI and MACD as price-scaled echo lines, with toggles to show/hide and customizable scaling (high/low or ATR).
**Who Is This For?**
- **Trend Traders**: Use MACD normalizations and MTF to identify momentum shifts across timeframes.
- **Mean-Reversion Traders**: Leverage VW-RSI’s overbought/oversold signals for entry/exit points.
- **Technical Analysts**: Customize normalization and smoothing to match specific market conditions.
- **All Markets**: Works on stocks, forex, cryptocurrencies, and more, with any timeframe.
**Notes**
- Unbounded MACD normalizations (`enable_nvw`, `enable_vol`) may produce values outside -50/+50, suitable for volatility-focused strategies.
- For price chart overlay, publish this script and use its ID in the companion script’s `request.security` call.
- Adjust scaling inputs in the companion script for optimal visualization on volatile or stable assets.
**Author’s Note**
Developed by NEPOLIX, this indicator combines volume-weighted precision with flexible normalization for robust technical analysis. Feedback and suggestions are welcome to enhance future versions!
HFT Judes scannerThis script tracks volume spikes along with stochastics and VWAP and helps identify institutional footprint
Volume Bandar Detector//@version=5
indicator("Broker Net Volume + Akumulasi", overlay=false, max_lines_count=500)
// --- Input setting ---
threshold = input.float(0.5, "Ambang Akumulasi (dalam % dari volume)", step=0.1)
maLength = input.int(5, "Panjang MA Net Volume", minval=1)
// --- Data dasar ---
buyVolume = volume * close / close // sementara pakai total volume (TradingView tidak bisa akses data broker real)
sellVolume = volume - buyVolume // dummy, hanya untuk contoh
// --- Net Volume ---
netVolume = buyVolume - sellVolume
// --- MA Net Volume ---
netVolMA = ta.sma(netVolume, maLength)
// --- Warna Histogram ---
barColor = netVolume >= 0 ? color.new(color.green, 0) : color.new(color.red, 0)
// --- Highlight Akumulasi (bar kuning) ---
highlight = netVolume > (threshold * volume)
// --- Plot Histogram Net Volume ---
plot(netVolume, style=plot.style_columns, color=highlight ? color.yellow : barColor, title="Net Volume")
// --- Plot Garis MA Net Volume ---
plot(netVolMA, color=color.blue, title="MA Net Volume", linewidth=2)
VOLUME Full [Titans_Invest]VOLUME Full
Designed for traders who want to take volume analysis to the next level.
This version delivers deeper insight into volume activity, integrating multiple customizable filters to highlight key buying and selling pressure. It's a comprehensive solution for volume-based decision-making.
⯁ WHAT IS THE VOLUME❓
The Volume indicator is a fundamental technical analysis tool that measures the number of shares or contracts traded in a security or market during a given period. It helps traders and investors understand the strength or weakness of a price movement, confirm trends, and predict potential reversals. Volume is typically displayed as a histogram below a price chart, with each bar representing the volume traded during a specific time interval.
⯁ HOW TO USE THE VOLUME❓
The Volume indicator can be used in several ways to enhance trading decisions:
• Trend Confirmation: High volume during a price move confirms the strength of that trend, while low volume can indicate a weak or unsustainable trend.
• Breakouts: A price breakout from a pattern or range accompanied by high volume is more likely to be valid and sustainable.
• Divergence: When the price moves in one direction and volume moves in the opposite direction, it can signal a potential reversal.
• Overbought/Oversold Conditions: Extreme volume levels can sometimes indicate that an asset is overbought or oversold, though this is less straightforward than with oscillators like the RSI.
⯁ ENTRY CONDITIONS
The conditions below are fully flexible and allow for complete customization of the signal.
______________________________________________________
🔹 CONDITIONS TO BUY 📈
______________________________________________________
▪︎ Signal Validity: The signal will remain valid for X bars .
▪︎ Signal Sequence: Configurable as AND or OR .
🔹 volume Positive
🔹 volume Negative
🔹 volume > volume
🔹 volume < volume
🔹 volume > volume_MA
🔹 volume > volume_MA * Trigger Signal (close > open)
🔹 volume > volume_MA * Trigger Signal (Keep State P)
🔹 volume > volume_MA * Trigger Signal (close < open)
🔹 volume > volume_MA * Trigger Signal (Keep State N)
______________________________________________________
______________________________________________________
🔸 CONDITIONS TO SELL 📉
______________________________________________________
▪︎ Signal Validity: The signal will remain valid for X bars .
▪︎ Signal Sequence: Configurable as AND or OR .
🔸 volume Positive
🔸 volume Negative
🔸 volume > volume
🔸 volume < volume
🔸 volume > volume_MA
🔸 volume > volume_MA * Trigger Signal (close > open)
🔸 volume > volume_MA * Trigger Signal (Keep State P)
🔸 volume > volume_MA * Trigger Signal (close < open)
🔸 volume > volume_MA * Trigger Signal (Keep State N)
______________________________________________________
______________________________________________________
🤖 AUTOMATION 🤖
• You can automate the BUY and SELL signals of this indicator.
______________________________________________________
______________________________________________________
⯁ UNIQUE FEATURES
______________________________________________________
Signal Validity: The signal will remain valid for X bars
Signal Sequence: Configurable as AND/OR
Condition Table: BUY/SELL
Condition Labels: BUY/SELL
Plot Labels in the Graph Above: BUY/SELL
Displays Positive & Negative Volume.
Automate and Monitor Signals/Alerts: BUY/SELL
Signal Validity: The signal will remain valid for X bars
Signal Sequence: Configurable as AND/OR
Table of Conditions: BUY/SELL
Conditions Label: BUY/SELL
Plot Labels in the graph above: BUY/SELL
Displays Positive & Negative Volume.
Automate & Monitor Signals/Alerts: BUY/SELL
______________________________________________________
📜 SCRIPT : VOLUME Full
🎴 Art by : @Titans_Invest & @DiFlip
👨💻 Dev by : @Titans_Invest & @DiFlip
🎑 Titans Invest — The Wizards Without Gloves 🧤
✨ Enjoy!
______________________________________________________
o Mission 🗺
• Inspire Traders to manifest Magic in the Market.
o Vision 𐓏
• To elevate collective Energy 𐓷𐓏
One White Soldier & One Black Crow DetectorOne white soldier & one black crow.
Blue and yellow highlights
Clean Volume BarsAs it says, simple clean volume indicator.
I could find what I wanted so I created this using AI.
Here is the script:
//@version=5
indicator("Clean Volume Bars", shorttitle="Clean Vol", overlay=false)
vma = ta.sma(volume, 20)
col = close>open? color.new(color.green,0) : close
Combined Cluster & Market StructureI barrowed code from the Mxwll Price Action Suite script as appreciated the structure in which the script defined structure, however I renamed variables and reduced the original script to define only the outer structure. I added volume and CVD clustering to define ranges and initiation market structures and add the ADX to assist with determining trend strength prior to labeling market structure breaks.
Combined Cluster & Market Structure indicator, a powerful and comprehensive tool for technical analysis. This script integrates two core concepts to provide a holistic view of market dynamics:
Z-Score Clustering & Volume Analysis: The indicator calculates Z-scores for both volume and Cumulative Volume Delta (CVD) to categorize market activity into six distinct clusters:
High-Conviction Bullish/Bearish: Signals of strong directional momentum based on high volume and corresponding CVD.
Effort vs. Result: High volume with moderate CVD, suggesting potential indecision or absorption.
Quiet Accumulation/Distribution: Low-volume periods with strong CVD, often preceding major moves.
Low Conviction/Noise: Represents periods of low market participation and weak signals.
These clusters are visually marked on the chart to provide real-time insight into market sentiment.
Market Structure Mapping: The indicator automatically detects and labels significant structural points to help you navigate price action. It identifies:
Higher Highs (HH) and Lower Lows (LL) to show the primary trend direction.
Breaks of Structure (BoS), indicating trend continuation.
Changes of Character (CHoCH), signaling a potential trend reversal.
Additionally, the script features consolidation box detection, which automatically highlights periods of low-conviction market activity, helping you avoid choppy, sideways markets. An integrated ADX filter ensures that structural breaks are only labeled during periods of strong trend strength, reducing false signals.
I want to thank Mxwll Capital for their contribution to the Combined Cluster & Market Structure indicator.
AVGO Advanced Day Trading Strategy📈 Overview
The AVGO Advanced Day Trading Strategy is a comprehensive, multi-timeframe trading system designed for active day traders seeking consistent performance with robust risk management. Originally optimized for AVGO (Broadcom), this strategy adapts well to other liquid stocks and can be customized for various trading styles.
🎯 Key Features
Multiple Entry Methods
EMA Crossover: Classic trend-following signals using fast (9) and medium (16) EMAs
MACD + RSI Confluence: Momentum-based entries combining MACD crossovers with RSI positioning
Price Momentum: Consecutive price action patterns with EMA and RSI confirmation
Hybrid System: Advanced multi-trigger approach combining all methodologies
Advanced Technical Arsenal
When enabled, the strategy analyzes 8+ additional indicators for confluence:
Volume Price Trend (VPT): Measures volume-weighted price momentum
On-Balance Volume (OBV): Tracks cumulative volume flow
Accumulation/Distribution Line: Identifies institutional money flow
Williams %R: Momentum oscillator for entry timing
Rate of Change Suite: Multi-timeframe momentum analysis (5, 14, 18 periods)
Commodity Channel Index (CCI): Cyclical turning points
Average Directional Index (ADX): Trend strength measurement
Parabolic SAR: Dynamic support/resistance levels
🛡️ Risk Management System
Position Sizing
Risk-based position sizing (default 1% per trade)
Maximum position limits (default 25% of equity)
Daily loss limits with automatic position closure
Multiple Profit Targets
Target 1: 1.5% gain (50% position exit)
Target 2: 2.5% gain (30% position exit)
Target 3: 3.6% gain (20% position exit)
Configurable exit percentages and target levels
Stop Loss Protection
ATR-based or percentage-based stop losses
Optional trailing stops
Dynamic stop adjustment based on market volatility
📊 Technical Specifications
Primary Indicators
EMAs: 9 (Fast), 16 (Medium), 50 (Long)
VWAP: Volume-weighted average price filter
RSI: 6-period momentum oscillator
MACD: 8/13/5 configuration for faster signals
Volume Confirmation
Volume filter requiring 1.6x average volume
19-period volume moving average baseline
Optional volume confirmation bypass
Market Structure Analysis
Bollinger Bands (20-period, 2.0 multiplier)
Squeeze detection for breakout opportunities
Fractal and pivot point analysis
⏰ Trading Hours & Filters
Time Management
Configurable trading hours (default: 9:30 AM - 3:30 PM EST)
Weekend and holiday filtering
Session-based trade management
Market Condition Filters
Trend alignment requirements
VWAP positioning filters
Volatility-based entry conditions
📱 Visual Features
Information Dashboard
Real-time display of:
Current entry method and signals
Bullish/bearish signal counts
RSI and MACD status
Trend direction and strength
Position status and P&L
Volume and time filter status
Chart Visualization
EMA plots with customizable colors
Entry signal markers
Target and stop level lines
Background color coding for trends
Optional Bollinger Bands and SAR display
🔔 Alert System
Entry Alerts
Customizable alerts for long and short entries
Method-specific alert messages
Signal confluence notifications
Advanced Alerts
Strong confluence threshold alerts
Custom alert messages with signal counts
Risk management alerts
⚙️ Customization Options
Strategy Parameters
Enable/disable long or short trades
Adjustable risk parameters
Multiple entry method selection
Advanced indicator on/off toggle
Visual Customization
Color schemes for all indicators
Dashboard position and size options
Show/hide various chart elements
Background color preferences
📋 Default Settings
Initial Capital: $100,000
Commission: 0.1%
Default Position Size: 10% of equity
Risk Per Trade: 1.0%
RSI Length: 6 periods
MACD: 8/13/5 configuration
Stop Loss: 1.1% or ATR-based
🎯 Best Use Cases
Day Trading: Designed for intraday opportunities
Swing Trading: Adaptable for longer-term positions
Momentum Trading: Excellent for trending markets
Risk-Conscious Trading: Built-in risk management protocols
⚠️ Important Notes
Paper Trading Recommended: Test thoroughly before live trading
Market Conditions: Performance varies with market volatility
Customization: Adjust parameters based on your risk tolerance
Educational Purpose: Use as a learning tool and customize for your needs
🏆 Performance Features
Detailed performance metrics
Trade-by-trade analysis capability
Customizable risk/reward ratios
Comprehensive backtesting support
This strategy is for educational purposes. Past performance does not guarantee future results. Always practice proper risk management and consider your financial situation before trading.
